Image preview - the first page of the document



>> Download 05. Front Drive Shaft documenatation <<

Text preview - extract from the document

                                       FRONT DRIVE SHAFT
                                                                                      DRIVE SHAFT SYSTEM

5. Front Drive Shaft                                     B: INSTALLATION
                                                         1) Insert the BJ into hub splines.
A: REMOVAL
1) Jack-up the vehicle, support it with rigid racks,     CAUTION:
and then remove the front wheel cap and wheels.          Be careful not to damage the inner oil seal lip
2) Raise the caulking portion of axle nut.               and tone wheel.
3) Depress the brake pedal and remove the axle           2) Using the ST1 and ST2, pull the drive shaft into
nut using a socket wrench.                               place.
                                                         ST1 922431000 AXLE SHAFT INSTALLER
CAUTION:
                                                         ST2 927390000 ADAPTER
Be sure to loosen the axle nut after removing
the wheel from vehicle. Failure to follow this
rule may damage the wheel bearings.
4) Remove the stabilizer link from transverse link.
5) Disconnect the transverse link from housing.
6) Remove the spring pin which secures the trans-
mission spindle to SFJ.


                                                                                ST
                                                                                                 DS-00104

                                                         3) Tighten the axle nut temporarily.
                                                         4) Install the SFJ on transmission spindle and drive
                                                         a new spring pin into place.


                                          DS-00204

7) Remove the front drive shaft assembly. If it is
hard to remove, use the ST1 and ST2.
ST1 926470000 AXLE SHAFT PULLER
ST2 927140000 AXLE SHAFT PULLER
                   PLATE
CAUTION:
