Image preview - the first page of the document
06. Subaru Select Monitor


>> Download 06. Subaru Select Monitor documenatation <<

Text preview - extract from the document
                                   SUBARU SELECT MONITOR
ABS (DIAGNOSTICS)

6. Subaru Select Monitor                               CAUTION:
                                                       Do not connect the scan tools except for Suba-
A: OPERATION                                           ru Select Monitor and OBD-II general scan tool.
1. READ DIAGNOSTIC TROUBLE CODE                        5) Turn the ignition switch to ON (engine OFF) and
(DTC)                                                  Subaru Select Monitor switch to ON.
1) Prepare the Subaru Select Monitor kit.
                                                                                                 (1)




                                                                                                       ABS00114

                                        ABS00111
                                                                 (1) Power switch
2) Connect the diagnosis cable to Subaru Select        6) On the
