Image preview - the first page of the document



>> Download 04. Front Disc Brake Assembly documenatation <<

Text preview - extract from the document

                              FRONT DISC BRAKE ASSEMBLY
BRAKE

4. Front Disc Brake Assembly                         NOTE:
                                                     Remove the support only when replacing it or the
A: REMOVAL                                           rotor. It need not be removed when servicing the
1. 15 INCH TYPE                                      caliper body assembly.

CAUTION:
Do not allow brake fluid to come in contact with
vehicle body; wash away with water and wipe
off completely if spilled.
1) Set the vehicle on a lift.
2) Loosen the wheel nuts.
3) Lift-up the vehicle, and then remove the front
wheel.
4) Remove the union bolt, and then disconnect the
brake hose from caliper body assembly.                                                      BR-00023

                                                     8) Clean mud and foreign particles from the caliper
                                                     body assembly and support.
                                                     2. 16 INCH TYPE
                                                     CAUTION:
                                                     Do not allow brake fluid to come in contact with
                                                     vehicle body; wash away with water and wipe
                                                     off completely if spilled.
                                                     1) Set the vehicle on a lift.
                                      BR-00021       2) Loosen the wheel nuts.
                                                     3) Lift-up the vehicle, and then remove the front
5) Remove the bolt securing lock pin to caliper      wheel.
body.                                                4) Remove the union bolt, and then disconnect the
                                                     brake hose from caliper body assembly.
                                                     5) Remove the caliper body from housing.




                                      BR-00022

6) Raise the caliper body, and then move it toward
vehicle center to separate it from support.                                                 BR-00298

7) Remove the support from housing.                  6) Clean mud and foreign particles from the caliper
                                                     body assembly and support.
                                                     3. 17 INCH TYPE
                                                     CAUTION:
                                                     Do not allow brake fluid to come in contact with
                                                     vehicle body; wash away with water and wipe
                                                     off completely if spilled.
                                                     1) Set the vehicle on a lift.
                                                     2) Loosen the wheel nuts.
                                                     3) Lift-up the vehicle, and then remove the front
                                                     wheel.



                                                 BR-22
                                FRONT DISC BRAKE ASSEMBLY
                                                                                                         BRAKE

4) Remove the brake pads from caliper body. .                                                    2. 16 INCH TYPE
5) Remove the union bolt and brake hose from cal-         1) Install the caliper body on housing.
iper body assembly.
                                                          Tightening torque:
6) Remove two installation bolts from housing.
                                                             80 N
