Image preview - the first page of the document



>> Download 05. Rear Brake Pad documenatation <<

Text preview - extract from the document

                                          REAR BRAKE PAD
BRAKE

5. Rear Brake Pad                                       2. 17 INCH TYPE
A: REMOVAL                                              1) Set the vehicle on a lift.
                                                        2) Loosen the wheel nuts.
1. 14 INCH TYPE                                         3) Lift-up the vehicle, and then remove the rear
                                                        wheel.
1) Set the vehicle on a lift.
2) Loosen the wheel nuts.                               4) Remove the clip.
3) Lift-up the vehicle, and then remove the rear
wheel.
4) Remove the lower caliper bolt.                                                              (1)




                                                                                                 BR-00313


                                                              (1) Clip
                                        BR-00123        5) Remove the pad pins and cross spring.
5) Raise the caliper body upward and support it.
NOTE:                                                                                    (1)
Do not disconnect the brake hose from caliper
body.
6) Remove the pad.
NOTE:
If the brake pad is difficult to remove, use the same
procedure as for front disc brake pad.
                                 (2)
                                                                                                 BR-00311


                                                              (1) Cross spring
                                                              (2) Pad pin

                                                        6) Expand the pads and push piston back.
                                                        7) Remove the pad.




                                        BR-00032




                                                                                   (1)
                                                                                                 BR-00312


                                                              (1) Rear brake pad




                                                   BR-28
                                              REAR BRAKE PAD
                                                                                                             BRAKE

B: INSTALLATION                                                2. 17 INCH TYPE
1. 14 INCH TYPE                                                Check the pad thickness A.
1) Apply a thin coat of Molykote AS880N (Part No.
K0777YA010) to the frictional portion between pad
and pad clip.
2) Install the pad on support.
3) Install the caliper body on support.
Tightening torque:
  37 N
