Image preview - the first page of the document



>> Download 06. Rear Disc Rotor documenatation <<

Text preview - extract from the document

                                            REAR DISC ROTOR
BRAKE

6. Rear Disc Rotor                                            (2) If the disc rotor seizes up within hub, drive
                                                              the disc rotor out by installing an 8-mm bolt in
A: REMOVAL                                                    holes B on rotor.
1) Set the vehicle on a lift.
2) Loosen the wheel nuts.
3) Lift-up the vehicle, and then remove the wheels.
4) Pull down and release the parking brake.
5) Remove the two mounting bolts, and then re-
move the disc brake assembly.


                                                                                             B
                                                                          A
                                                                                                   BR-00036

                                                          B: INSTALLATION
                                                          1) Install in the reverse order of removal.
                                                          2) Adjust the parking brake.

6) Suspend the disc brake assembly so that hose is        C: INSPECTION
not stretched.                                            1) Check bearing axial end play and hub runout be-
7) Remove the disc rotor.                                 fore disc rotor runout limit inspection.
NOTE:                                                     2) Secure the disc rotor by tightening five wheel
If the disc rotor is difficult to remove try following    nuts.
two methods in order.                                     3) Set a dial gauge 10 mm (0.39 in) inward of rotor
    (1) Turn the adjusting screw using a flat tip         outer perimeter. Turn the disc rotor to check runout.
    screwdriver until brake shoe gets away enough         If the disc rotor runout is above specified value, re-
    from the disc rotor.                                  place the disc rotor.

                             (2)


                                     (3)




        (1)


                       (4)
                                           BR-00155                                                BR-00037


        (1)   Adjusting screw                             Disc rotor runout limit:
        (2)   Cover                                         0.070 mm (0.0027 in)
        (3)   Flat tip screwdriver
        (4)   Back plate




                                                      BR-30
                                              REAR DISC ROTOR
                                                                    BRAKE

4) Set a micrometer 10 mm (0.39 in) inward of the
rotor outer perimeter, and then measure the disc
rotor thickness. If the thickness of disc rotor is out-
side the service limit, replace the disc rotor.




                                   B
                A
                                             BR-00036


                    Standard     Service       Disc outer
                      value        limit          dia.
                     10 mm       8.5 mm         266 mm
              14
Disc rotor          (0.39 in)   (0.335 in)     (10.47 in)
thickness A          20 mm        18 mm         316 mm
              17
                    (0.79 in)    (0.71 in)     (12.44 in)




                                                            BR-31
