Image preview - the first page of the document
07. Rear Disc Brake Assembly


>> Download 07. Rear Disc Brake Assembly documenatation <<

Text preview - extract from the document
                                REAR DISC BRAKE ASSEMBLY
BRAKE

7. Rear Disc Brake Assembly                           6) Remove the caliper body from housing.

A: REMOVAL
1. 14 INCH TYPE
CAUTION:
Do not allow brake fluid to come in contact with
vehicle body; wash away with water and wipe
off completely if spilled.
1) Set the vehicle on a lift.
2) Loosen the wheel nuts.
                                                                                                BR-00315
3) Lift-up the vehicle, and then remove the wheels.
4) Disconnect the brake hose from caliper body as-    7) Clean mud and foreign particles from the caliper
sembly.                                               body.
5) Remove the bolt securing lock pin to caliper       CAUTION:
body.                                                 Be careful not to allow foreign particles to enter
                                                      brake hose connector.
                                                      B: INSTALLATION
                                                      1. 14 INCH TYPE
                                                      1) Install the support on housing.
                                                      Tightening torque:
                                                         52 N
