Image preview - the first page of the document

>> Download 02. Front Brake Pad documenatation <<

Text preview - extract from the document

FRONT BRAKE PAD
BRAKE

2. Front Brake Pad (4) Attach a rod of less than 12 mm (0.47 in) dia.
to the shaded area of brake pad, and strike the
A: REMOVAL rod with a hammer to drive brake pad out of
place.
1. 15 INCH TYPE
1) Set the vehicle on a lift.
2) Loosen the wheel nuts.
3) Lift-up the vehicle, and then remove the front
wheel.
4) Remove the lower caliper bolt.
5) Raise the caliper body upward and support it.
NOTE:
Do not disconnect the brake hose from caliper
body. BR-00014
6) Remove the pad.
2. 16 INCH TYPE
1) Set the vehicle on a lift.
2) Loosen the wheel nuts.
3) Lift-up the vehicle, and then remove the front
wheel.
4) Remove the M clip.

(1)
BR-00012

NOTE:
If the brake pad is difficult to remove, proceed as
follows:
(1) Remove the caliper body from support.
(2) Remove the support.
BR-00288
(3) Place a support in a vise between wooden
blocks.
(1) M clip
(1)
5) Remove the pad pins, then remove the cross
spring.

(2) BR-00013

(1) Support (2) (1)
(2) Wooden blocks BR-00289

(1) Pad pin
(2) Cross spring

BR-16
FRONT BRAKE PAD
BRAKE

6) Use a wrench to expand the pads, and then 5) Remove the pad pins and cross spring.
push the piston back.

(2)

(1)

BR-00293
BR-00290
(1) Pad pin
7) Remove the pad.
(2) Cross spring

6) Use a wrench to expand the pads, and then
push the piston back.

BR-00291

3. 17 INCH TYPE
1) Set the vehicle on a lift. BR-00290
2) Loosen the wheel nuts.
7) Remove the pad.
3) Lift-up the vehicle, and then remove the front
wheel.
4) Remove the clip.

(1)
BR-00291

BR-00292

(1) Clip

BR-17
FRONT BRAKE PAD
BRAKE

B: INSTALLATION 3. 17 INCH TYPE
1. 15 INCH TYPE 1) Apply thin coat of Molykote AS880N (Part No.
K0779YA010) to the frictional portion between pad
1) Apply thin coat of Molykote AS880N (Part No. and pad shim.
K0779YA010) to the frictional portion between pad
and pad clip.
2) Apply thin coat of Molykote AS880N (Part No.
K0779YA010) to the frictional portion between pad
and pad inner shim.

BR-00295

2) Install the pads on caliper body.
3) Install the cross spring.
4) Install the pad pins.
BR-00238 5) Install the clip.
3) Install the pads on support. C: INSPECTION
4) Install the caliper body on support. 1. 15 INCH TYPE
Tightening torque: Check the pad thickness A.
37 N
