Image preview - the first page of the document



>> Download 03. Front Disc Rotor documenatation <<

Text preview - extract from the document

                                          FRONT DISC ROTOR
BRAKE

3. Front Disc Rotor                                      4) Remove the caliper body from housing and sus-
                                                         pend from strut using a wire.
A: REMOVAL
1. 15 INCH TYPE
1) Set the vehicle on a lift.
2) Loosen the wheel nuts.
3) Lift-up the vehicle, and then remove the front
wheel.
4) Remove the caliper body and support from
housing, and suspend it from strut using a wire.
                                                                                                   BR-00297

                                                         5) Remove the disc rotor from hub.
                                                         NOTE:
                                                         If the disc rotor seizes up within the hub, drive the
                                                         disc rotor out by installing an 8-mm bolt in holes B
                                                         on rotor.


                                          BR-00017

5) Remove the disc rotor.
NOTE:
If the disc rotor seizes up within the hub, drive the
disc rotor out by installing an 8-mm bolt in holes (B)                                         B
on rotor.                                                            A

                                                                                                   BR-00018

                                                         6) Clean mud and foreign particles from the caliper
                                                         body assembly and support.
                                                         B: INSTALLATION
                                                         1) Install the disc rotor.
                                      B                  2) Install the caliper body and support to housing.
            A
                                                         Tightening torque:
                                          BR-00018
                                                            Except 17 inch type:
                                                              80 N
