Image preview - the first page of the document
>> Download 04. Parking Brake Assembly (Rear Disc Brake) documenatation <<
Text preview - extract from the document
PARKING BRAKE ASSEMBLY (REAR DISC BRAKE)
PARKING BRAKE
4. Parking Brake Assembly (2) If the disc rotor seizes up within hub, drive
the disc rotor out by installing two 8-mm bolts in
(Rear Disc Brake) holes B on rotor.
A: REMOVAL
1) Pull down and release the parking brake.
2) Remove the two mounting bolts and remove the
brake caliper assembly.
(1)
B
A
BR-00036
5) Remove the shoe return spring from parking
brake assembly.
6) Remove the front shoe hold-down spring and pin
BR-00034 with pliers.
(1) Brake caliper assembly
3) Suspend the brake caliper assembly so that the
hose is not stretched.
4) Remove the disc rotor.
NOTE:
If the disc rotor is difficult to remove, try the two fol-
lowing methods in order.
(1) Turn the adjusting screw using a flat tip
PB-00013
screwdriver until brake shoe gets away enough
from the disc rotor. 7) Remove the strut and strut spring.
8) Remove the adjuster assembly from parking
(2) brake assembly.
9) Remove the brake shoe.
(3) 10) Remove the rear shoe hold-down spring and
pin with pliers.
11) Remove the parking brake cable from parking
(1) brake lever.
(4)
PB-00020
(1) Adjusting screw
(2) Adjusting hole cover (rubber)
(3) Flat tip screwdriver
(4) Back plate
PB-00014
(1) Parking brake cable
(2) Parking brake lever
12) Using a standard screwdriver, raise the retain-
er. Remove the parking brake lever and washer
from brake shoe.
PB-6
PARKING BRAKE ASSEMBLY (REAR DISC BRAKE)
PARKING BRAKE
B: INSTALLATION ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
