Image preview - the first page of the document



>> Download 05. Steering Gearbox documenatation <<

Text preview - extract from the document

                                       STEERING GEARBOX
                                                            POWER ASSISTED SYSTEM (POWER STEERING)

5. Steering Gearbox                                     10) Remove the one pipe joint at center of gearbox,
                                                        and connect vinyl hose to pipe and joint. Discharge
A: REMOVAL                                              fluid by turning the steering wheel fully clockwise
1) Set the vehicle on a lift.                           and counterclockwise. Discharge fluid similarly
2) Disconnect the ground cable from battery.            from the other pipe.
3) Loosen the front wheel nut.
4) Lift-up the vehicle, and then remove the front
wheels.
                                                                            (2)
5) Remove the under cover.
6) Remove the sub frame.
7) Remove the front exhaust pipe assembly. (Non-
                                                                             (1)
turbo model)

                                                                                                   PS-00026
WARNING:
Be careful, the exhaust pipe is hot.                           (1) Pipe A
8) Using a puller, remove the tie-rod end from                 (2) Pipe B
knuckle arm after pulling off cotter pin and remov-
ing castle nut.                                         11) Remove the universal joint.
                                                        12) Disconnect the lower pipe C from gear box first,
                                                        and upper pipe D second.




                                                                                   (1)       (2)
                                       PS-00043


       (1) Castle nut
       (2) Tie-rod end                                                                             PS-00027

       (3) Knuckle arm
                                                               (1) Pipe C
9) Remove the jack-up plate and front stabilizer.              (2) Pipe D

                                                        13) Remove the clamp bolts securing the gearbox
                                                        to crossmember, and then remove the gearbox.

                                                                                                    (1)




                                       PS-00044


       (1) Jack-up plate
                                                                                                   PS-00028


                                                               (1) Clamp




                                                    PS-23
                                      STEERING GEARBOX
POWER ASSISTED SYSTEM (POWER STEERING)

B: INSTALLATION                                          6) After tightening the castle nut to specified
1) Insert the gearbox into crossmember, being            torque, tighten it further within 60
