Image preview - the first page of the document



>> Download 06. Pipe Assembly documenatation <<

Text preview - extract from the document

                                            PIPE ASSEMBLY
                                                            POWER ASSISTED SYSTEM (POWER STEERING)

6. Pipe Assembly                                         4) Remove the clamp E from pipes C and D.

A: REMOVAL
1) Disconnect the ground cable from battery.                                            (1)
2) Lift-up the vehicle, and then remove the jack-up
plate.

                                                                                 (3)

                                                                                                        (2)
                                                                     (5)




                                                                                       (4)



                                         PS-00044


       (1) Jack-up plate

3) Remove the one pipe joint at the center of gear-
box, and then connect the vinyl hose to pipe and
joint. Discharge fluid by turning steering wheel fully
clockwise and counterclockwise. Discharge fluid                                                     PS-00176

similarly from the other pipe.
                                                               (1)     Return hose
                                                               (2)     Pressure hose
                                                               (3)     Clamp E
                    (2)                                        (4)     Pipe C
                                                               (5)     Pipe D

                                                         5) Disconnect the pipe C and D from gear box.
                     (1)



                                         PS-00026


       (1) Pipe A
       (2) Pipe B                                                                             (2)
                                                                                (1)




                                                                                                    PS-00027


                                                               (1) Pipe C
                                                               (2) Pipe D




                                                    PS-41
                                        PIPE ASSEMBLY
POWER ASSISTED SYSTEM (POWER STEERING)

6) NON-TURBO MODEL                                  7) TURBO MODEL
   (1) Remove the air intake duct.
   (3) Disconnect the pipe C from oil pump. Dis-       (2) Remove the coolant filler tank.
   connect the pipe D from return hose.
CAUTION:
