Image preview - the first page of the document



>> Download 09. Power Steering Fluid documenatation <<

Text preview - extract from the document

                                      POWER STEERING FLUID
                                                                 POWER ASSISTED SYSTEM (POWER STEERING)

9. Power Steering Fluid                                      C: REPLACEMENT
                                                             1) Lift up the vehicle.
A: SPECIFICATION                                             2) Remove the jack up plate.
   Recommended power steering fluid       Manufacturer       3) Remove the pipe joint in center of gear box, and
                                              B.P.           then install the vinyl hose to pipe and joint. Drain
                                            CALTEX           the fluid while turning steering wheel.
                                           CASTROL
                                                             4) Set the ST on top of reservoir tank and fill it
     ATF DEXRON III or equivalent                            about half way with the specified fluid.
                                             MOBIL
                                                             ST 34199AE040 OIL CHARGE
                                            SHELL
                                           TEXACO

B: INSPECTION
1) Check the power steering fluid for deterioration
or contamination. If the fluid is highly deteriorated
or contaminated, drain it and refill with new fluid.
2) Check the joints and units for oil leakage. If any
oil leaks are found, repair or replace the applicable
part.
3) Inspect the fluid level on flat and level surface                                                     PS-00160
with engine "OFF" by indicator of reservoir tank.
If the level is at MIN. point or below, add fluid to         5) Continue to turn the steering wheel slowly from
keep the level in the specified range of the indica-         lock to lock until bubbles stop appearing on oil sur-
tor. If at MAX. point or above, drain fluid by using a       face while keeping the fluid at that level.
syringe or the like.                                         6) If turning the steering wheel in low fluid level
    (1) Check at power steering fluid temperature            condition, air will be sucked in pipe. In this case,
    20
