Image preview - the first page of the document



>> Download 07. Blower Motor Unit Assembly documenatation <<

Text preview - extract from the document

                             BLOWER MOTOR UNIT ASSEMBLY
HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

7. Blower Motor Unit Assembly                         6) Loosen the bolt and nut to remove the blower
                                                      motor unit assembly.
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the glove box.
3) Loosen the nut to remove the support beam
stay.




                                                                                                 AC-00616

                                                      B: INSTALLATION
                                                      Install in the reverse order of removal.
                                                      Tightening torque:
                                                        Refer to COMPONENT in General Descrip-
                                       AC-00218         tion.  and

                                                      C: INSPECTION
                                                      Connect the motor connector terminal 1 from the
                                                      battery to the positive (+) lead and terminal 2 to the
                                                      negative (-) lead. Make sure the motor runs
                                                      smoothly.


                                       AC-00614

5) Disconnect the power transistor or blower resis-
tor connector.




                                                                                                 AC-00617




                                       AC-00615




                                                  AC-26
