Image preview - the first page of the document
11. Control Unit (Manual AC Model)


>> Download 11. Control Unit (Manual AC Model) documenatation <<

Text preview - extract from the document
                          CONTROL UNIT (MANUAL A/C MODEL)
HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

11.Control Unit (Manual A/C                           2) Remove the glove box.
   Model)                                             3) Remove the lower panel.
1) Disconnect the ground terminal from battery.       4) Remove the control wires.




                                                                                                     AC-00520


5) Remove the center console panel.                   6) Remove four screws.




         : (A)
                                      AC-00752                                                   AC-00521

                                                      7) Pull out the control unit and disconnect connec-
      (A) Clip
                                                      tors.
                                                      B: INSTALLATION
                                                      Install in the reverse order of removal.




                                                  AC-30
