Image preview - the first page of the document
13. Compressor


>> Download 13. Compressor documenatation <<

Text preview - extract from the document
                                           COMPRESSOR
HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

13.Compressor                                         8) Disconnect the compressor harness from body
                                                      harness.
A: INSPECTION                                         9) Loosen the bolts to remove the compressor
                                                      bracket.
1. MAGNETIC CLUTCH CLEARANCE
1) Check the clearance of the entire circumference
around the drive plate and pulley.
Standard:
  0.45
