Image preview - the first page of the document



>> Download 14. Condenser documenatation <<

Text preview - extract from the document

                                             CONDENSER
HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

14.Condenser                                          B: INSTALLATION
                                                      1) Install in the reverse order of removal.
A: REMOVAL
1) Using the refrigerant recovery system, dis-        CAUTION:
charge refrigerant.                       ones, and then apply compressor oil. Confirm
2) Disconnect the ground cable from battery.          that lower guide of condenser (A) has been fit-
3) Disconnect the pressure hose and pipe from         ted into holes on radiator panel.
condenser.




                                                                              (A)
                                                                                               AC-00631

                                       AC-00629
                                                      2) Charge refrigerant.
                                                      Tightening torque:
                                                        Refer to COMPONENT in General Descrip-
                                                        tion.
                                                        and
                                                      C: INSPECTION
                                                      1) Confirm that no dust or insects are found on the
              (A)
                                       AC-00053       condenser fins. Air-blow or flush fins with water as
                                                      needed.
5) Remove the two bolts. While lifting the condens-   2) Confirm that no oil leaks from condenser. If a
er, pull it out through the space between radiator    failure is found, replace the condenser with a new
and radiator panel.                                   one.




                                       AC-00630

CAUTION:
