Image preview - the first page of the document
15. Heater and Cooling Unit


>> Download 15. Heater and Cooling Unit documenatation <<

Text preview - extract from the document
                               HEATER AND COOLING UNIT
                                                        HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

15.Heater and Cooling Unit                          B: INSTALLATION
                                                    1) Install in the reverse order of removal.
A: REMOVAL                                          2) Charge refrigerant.
2) Using the refrigerant recovery system, dis-
charge refrigerant.                       Refer to COMPONENT in General Descrip-
3) Drain LLC from the radiator.                       tion.
pipe in engine compartment. Release the heater
hose clamps in engine compartment to remove the
hoses.




                                     AC-00632

5) Remove the instrument panel.
6) Remove the support beam.
7) Remove the blower motor unit assembly.
8) Disconnect the servo motor connectors.
9) Loosen the bolt and nuts to remove the heater
and cooling unit.




                                    AC-00055




                                                AC-35
