Image preview - the first page of the document
>> Download 18. Relay and Fuse documenatation <<
Text preview - extract from the document
RELAY AND FUSE
HVAC SYSTEM (HEATER, VENTILATOR AND A/C)
18.Relay and Fuse B: INSPECTION
A: LOCATION
1
2
4
(H)
3
(1)
(A)
(B)
(C) 2 1
(D)
(E) 3 4
(F)
(G)
AC-00641
(2)
AC-00640 (3) -- (4): Continuity exists.
(1) -- (2): No continuity
(1) Joint box While applying battery voltage to the terminal be-
(2) Main fuse box tween (3) and (4), check continuity between (1) and
(2).
Main Fan Relay 1 A If no continuity exists, replace the relay with a new
one.
Main Fan Relay 2 B
Sub Fan Relay 2 C
Sub Fan Relay 1 E
A/C Relay D
Main Fan Fuse F
Sub Fan Fuse G
A/C Fuse H
AC-38
