Image preview - the first page of the document
>> Download 02. General Description documenatation <<
Text preview - extract from the document
GENERAL DESCRIPTION
HVAC SYSTEM (AUTO A/C) (DIAGNOSTICS)
2. General Description NOTE:
Ensure the paper does not get sucked into the port.
A: CAUTION
1) Never connect the battery in reverse polarity.
The Auto A/C control module will be destroyed in-
stantly.
2) Do not disconnect the battery cables while the
engine is running.2
A large counter electromotive force will be generat-
ed in the alternator, and this voltage may damage
electronic parts such as A/C control module.
3) Before disconnecting the connectors of each (b) (a)
sensor and the A/C control module, be sure to turn AC-00747
off the ignition switch.
Otherwise, the Auto A/C control module may be 6) If the paper does not move at all, remove the
damaged. auto A/C control unit and check for im-
Do not drop them. proper connection of the aspirator hose (a), auto A/
5) Airbag system wiring harness is routed near the C control unit and heater unit, and secure as nec-
A/C control panel (A/C control module) and junction essary.
box.
CAUTION:
