Image preview - the first page of the document
>> Download 04. Driver's Airbag Module documenatation <<
Text preview - extract from the document
DRIVER'S AIRBAG MODULE
AIRBAG SYSTEM
4. Driver's Airbag Module B: INSTALLATION
Install in the reverse order of removal.
A: REMOVAL
CAUTION:
CAUTION: Do not allow harness and connectors to inter-
Refer to "CAUTION" in General Description be- fere or get tangled up with other parts.
fore handing the airbag module. Tightening torque:
1) Position the front wheels straight ahead. (After Refer to "COMPONENT" in "General Descrip-
moving the vehicle more than 5 m (16 ft) with front tion"
the vehicle moves straight ahead). C: INSPECTION
2) Turn the ignition switch to OFF.
CAUTION:
3) Disconnect the ground cable from battery, and
Refer to "CAUTION" in General Description be-
wait for at least 20 seconds before starting work.
fore handing the airbag module.
TORX bolts on side of steering wheel.
Check for the following, and replace damaged
parts with new parts.
