Image preview - the first page of the document



>> Download 06. Side Airbag Module documenatation <<

Text preview - extract from the document

                                        SIDE AIRBAG MODULE
AIRBAG SYSTEM

6. Side Airbag Module                                  7) Remove the side airbag module (A) from back-
                                                       rest frame assembly.
A: REMOVAL
CAUTION:
Before working on the airbag module, refer to
the "CAUTION" in General Description.
NOTE:
Remove the passenger's side by referring to driv-             (A)
er's side.
1) Turn the ignition switch to OFF.
2) Disconnect the ground cable from battery, and                                           AB-00476
wait for at least 20 seconds before starting work.
3) Remove the front seat from the vehicle.
4) Remove the clip, and then remove the side air-
bag harness from slide rail IN (A) and reverse side
of seat cushion assembly.




                                  (A)
                                        AB-00474

5) Remove the backrest cover.
6) Remove the side airbag harness from backrest
frame assembly.




                                        AB-00475


                                                   AB-14
                                       SIDE AIRBAG MODULE
                                                                                             AIRBAG SYSTEM

B: INSTALLATION                                         5) Install the side airbag harness to slide rail IN (A).
1) Ensure there are no foreign particles on side air-
bag module.
2) Install the side airbag module (A) to backrest
frame assembly.
Tightening torque:
  5.9 N
