Image preview - the first page of the document



>> Download 10. Front Sub Sensor documenatation <<

Text preview - extract from the document

                                           FRONT SUB SENSOR
                                                              AIRBAG SYSTEM

10.Front Sub Sensor
A: REMOVAL
1) Turn the ignition switch to OFF.
2) Disconnect the ground cable from battery, and
wait for at least 20 seconds before starting work.
3) Remove the front bumper.
4) Loosen the two bolts to remove the sensor cov-
er.




                                           AB-00486

5) Remove the bolt, and then detach the front sub
sensor.
6) Disconnect the connector from front sub sensor.




                                           AB-00487

B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
  Refer to "COMPONENT" in "General Descrip-
  tion"
C: INSPECTION
Check for the following, and replace damaged
parts with new parts.
