ELECTRICAL COMPONENTS LOCATION
AIRBAG SYSTEM (DIAGNOSTICS)
4. Electrical Components Location
A: LOCATION
(1) (2)
AB18 AB15
(3) (4)
B31
AB14 (a) (6)
AB1 (5)
AB13 (8)
(7) AB7
AB21
AB26
AB27 AB4
AB2
AB3
AB8
(10) (9)
(11)
AB19 AB20
AB9 AB28
(b) AB11 (c)
AB29
AB10 AB12
(14) (15)
(12) (13)
AB-00494
(1) Front sub sensor (LH) (7) Roll connector (14) Side airbag inflator (LH)
(2) Front sub sensor (RH) (8) Airbag main harness (15) Side airbag inflator (RH)
(3) Front sub sensor harness (LH) (9) Driver's airbag inflator (a) To body harness
(4) Front sub sensor harness (RH) (10) Side airbag harness (LH) (b) To seat belt pretensioner (LH)
(5) Airbag control module with built-in (11) Side airbag harness (RH) (c) To seat belt pretensioner (RH)
safety and electric sensor (12) Side airbag sensor (LH)
(6) Passenger's airbag inflator (13) Side airbag sensor (RH)
Connector
(AB1) (AB2) (AB3) (AB4) (AB7) (AB8) (AB9) (AB10) (AB11) (AB12) (AB13) (AB14)
No.
Pole 6 2 28 4 12 12 2 4 2 4 2 2
Color Yellow Black Yellow Yellow Yellow Yellow Yellow Yellow Yellow Yellow Yellow Yellow
Male/Female Male Female Female Female Female Female Female Female Female Female Female Male
Connector
(AB15) (AB18) (AB19) (AB20) (AB21) (AB26) (AB27) (AB28) (AB29)
No.
Pole 2 2 2 2 2 2 2 2 2
Color Yellow Yellow Black Black Yellow Yellow Yellow Yellow Yellow
Male/Female Female Female Female Female Female Male Male Male Male
AB-17
