Image preview - the first page of the document



>> Download 06. Airbag Connector documenatation <<

Text preview - extract from the document

                                        AIRBAG CONNECTOR
                                                                            AIRBAG SYSTEM (DIAGNOSTICS)

6. Airbag Connector                                         (2) With the lock arm (A) pushed in, move the
                                                            slide lock (B) in the direction of the arrow.
A: OPERATION
1. POWER SUPPLY                                                                            (B)

1) How to disconnect:
   (1) Move the slide lock (A) in the direction of the                                           (A)
   arrow.
   (2) Pull the female connector in the direction of
   the arrow with slide lock (A) moved.


                                                                                                       AB-00017

                                                            (3) With the slide lock (B) pulled, remove the
                                                            lock arm (A) to its original position, and then pull
                                                            in the direction of the arrow and separate the
                                                            connector.
                                                         CAUTION:
                                                         When pulling, be sure to hold onto the connec-
                                         AB-00015        tor and not the wire.

CAUTION:
When pulling, be sure to hold onto the connec-
tor and not the wire.
2) How to connect:
Holding the connector (A), and push it in carefully
until a connecting sound is heard.



                                                                                                       AB-00018

                                                         2) How to connect:
                                                         Holding the connector, and push it in carefully until
                                                         a connecting sound is heard.
                                                         CAUTION:
                                                         Be sure to insert the connector in until it locks.
                                         AB-00016        Then pull on it gently to make sure that it is
                                                         locked.
CAUTION:
Be sure to insert the connector in until it locks.
Then pull on it gently to make sure that it is
locked.
2. DRIVER'S AIRBAG (BETWEEN AIRBAG
MAIN HARNESS AND ROLL CONNECTOR),
PASSENGER'S AIRBAG AND SIDE AIR-
BAG
1) How to disconnect:
   (1) Push the lock arm (A).                                                                          AB-00019




                                                    AB-21
                                        AIRBAG CONNECTOR
AIRBAG SYSTEM (DIAGNOSTICS)

3. DRIVER'S AIRBAG MODULE AND PRE-                       4. FRONT SUB-SENSOR AND SIDE AIR-
TENSIONER                                                BAG SENSOR
1) How to disconnect:                                    1) How to disconnect:
   (1) Using a flat tip screwdriver, pry the push        Holding outer part (A), pull it in the direction of the
   lock upward to unlock.                                arrow.
                                                         CAUTION:
                                                         When pulling, be sure to hold onto the connec-
                                                         tor and not the wire.




                                         AB-00478

   (2) Pull the connector to disconnect from driv-
   er's side airbag module assembly or retractor
   assembly.                                                                                       AB-00024

                                                         2) How to connect:
                                                         Holding the connector, and push it in carefully until
                                                         a connecting sound is heard.
                                                         CAUTION:
