Image preview - the first page of the document



>> Download 05. Rear Seat Belt documenatation <<

Text preview - extract from the document

                                         REAR SEAT BELT
SEAT BELT SYSTEM

5. Rear Seat Belt                                     7) Remove the two bolts and adjustable anchor
                                                      ASSY.
A: REMOVAL
1. OUTER BELT RH AND LH (SEDAN MOD-
EL)
1) Remove the rear seat.
2) Remove the side sill rear lower cover.
3) Remove the seat belt lower anchor bolt.
                                                                                            SB-00087


                                                      2. SHOULDER BELT CTR (SEDAN MODEL)
                                                      1) Remove the rear seat.
                                                      2) Remove the seat belt lower anchor bolt.


                                      SB-00084

4) Remove the anchor cover. Remove the bolt and
shoulder anchor from pillar.



                                                                                            SB-00088

                                                      3) Remove the quarter pillar trim.
                                                      4) Remove the rear shelf trim.
                                                      5) Remove the bolts, and then detach the seat belt.
                                      SB-00085

5) Remove the quarter pillar trim.
6) Remove the bolts, and then detach the seat belt.




                                                                                            SB-00089




                                      SB-00086




                                                 SB-10
                                        REAR SEAT BELT
                                                                                   SEAT BELT SYSTEM

3. CENTER BELT (SEDAN MODEL)                         7) Remove the bolts, and then detach the outer belt
                                                     side.
1) Remove the rear cushion.
2) Remove the bolts, and then detach the inner
belt.




                                                                                           SB-00093

                                                     8) Remove the two bolts and adjustable anchor
                                                     ASSY.
                                      SB-00090


4. OUTER BELT RH AND LH (WAGON
MODEL)
1) Remove the luggage floor mat.
2) Remove the rear seat.
3) Remove the side sill rear lower cover.                                                          SB-00087
4) Remove the seat belt lower anchor bolt.
                                                     5. SHOULDER BELT CTR (WAGON MOD-
                                                     EL)
                                                     1) Remove the shoulder anchor bolt, and then de-
                                                     tach the shoulder anchor from quarter pillar.




                                     SB-00091

5) Remove the anchor cover. Remove the bolt and
shoulder anchor from pillar.

                                                                                           SB-00095

                                                     2) Remove the quarter trim.




                                     SB-00085

6) Remove the rear quarter trim.




                                                 SB-11
                                             REAR SEAT BELT
SEAT BELT SYSTEM

3) Remove the three bolts, and then detach the            3. CENTER BELT (SEDAN MODEL)
outer belt center.
                                                          Install in the reverse order of removal.
                                                          CAUTION:
                                                          During installation, make sure that the seat
                                                          belts are not twisted.
                                                          4. OUTER BELT RH AND LH (WAGON
                                                          MODEL)
                                                          Install in the reverse order of removal.
                                                          CAUTION:
                                       SB-00096
