Image preview - the first page of the document



>> Download 08. Combination Switch (Light) documenatation <<

Text preview - extract from the document

                                 COMBINATION SWITCH (LIGHT)
                                                                                                      LIGHTING SYSTEM

8. Combination Switch (Light)                                C: INSPECTION
                                                             Measure the combination switch resistance.
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the instrument panel lower cover.
3) Remove the screws which secure the upper col-
umn cover to lower column cover.




                                           LI-00009
                                                                                 8    7 6 5 4 3     2    1
                                                                                 17   16 1514131211 10   9
4) Disconnect the connector from combination
switch.                                                                                     (A)
5) Remove the screws which secure the switch,
and then remove the switch.
                                                                                                                LI-00244


                                                                    (A) Lighting and turn signal switch connector

                                                             1. LIGHTING SWITCH
                                                               Switch position        Terminal No.          Standard
                                                                    OFF                     --           More than 1 M
                                                                     Tail               14 and 16         Less than 1
                                                                    Head              13, 14 and 16       Less than 1
                                           LI-00068

B: INSTALLATION                                              2. DIMMER AND PASSING SWITCH
Install in the reverse order of removal.                       Switch position         Terminal No.            Standard
                                                                  Passing               7, 8 and 16          Less than 1
                                                                Low beam                 16 and 17           Less than 1
                                                                High beam                7 and 16            Less than 1

                                                             3. TURN SIGNAL SWITCH
                                                               Switch position         Terminal No.         Standard
                                                                    Left                 1 and 2          Less than 1
                                                                  Neutral                   --           More than 1 M
                                                                    Right                2 and 3          Less than 1




                                                      LI-9
