Image preview - the first page of the document
>> Download 10. Combination Base Switch Assembly documenatation <<
Text preview - extract from the document
COMBINATION BASE SWITCH ASSEMBLY
LIGHTING SYSTEM
10.Combination Base Switch 2. PARKING SWITCH
Assembly Measure the parking switch resistance.
A: REMOVAL
1) Remove the driver's airbag module.
2) Remove the steering wheel.
3) Remove the steering column cover.
4) Remove the combination switch. and
LI-00183
5) Loosen the four screws and remove the roll con-
nector. Switch position Terminal No. Standard
6) Loosen the three screws. OFF 2 and 4 Less than 1
ON 1 and 4 Less than 1
LI-00181
7) Disconnect the connector and remove the com-
bination base switch assembly.
B: INSTALLATION
1) Install in the reverse order of removal.
2) Align the attaching direction of roll connector
with the steering wheel, before installation of steer-
ing wheel.
C: INSPECTION
1. COMBINATION BASE SWITCH ASSEM-
BLY
Perform the inspection for the following items and
replace with a new one, if any damage is found.
