Image preview - the first page of the document
>> Download 17. Rear Combination Light Assembly documenatation <<
Text preview - extract from the document
REAR COMBINATION LIGHT ASSEMBLY
LIGHTING SYSTEM
17.Rear Combination Light As- 3) Remove two bolts, and then remove the rear
combination light while disconnecting connector.
sembly
A: REMOVAL
1. SEDAN
1) Disconnect the ground cable from battery.
2) Remove the clips, and then detach the trunk rear
trim.
LI-00211
LI-00208
3) Remove the trunk side trim of rear portion.
4) Remove the four nuts, and then detach the rear
combination light while disconnecting connector. LI-00231
B: INSTALLATION
Install in the reverse order of removal.
LI-00209
2. WAGON
1) Disconnect the ground cable from battery.
2) Remove the clips, and then detach the rear com-
bination light covers.
LI-00210
LI-20
