Image preview - the first page of the document



>> Download 18. Tail-Rear Side Marker-Stop Light Bulb documenatation <<

Text preview - extract from the document

                             TAIL/REAR SIDE MARKER/STOP LIGHT BULB
                                                                     LIGHTING SYSTEM

18.Tail/Rear Side Marker/Stop
   Light Bulb
A: REMOVAL
1. SEDAN
1) Remove the trunk side trim of rear portion.
2) Turn the socket and remove the bulb.




                                              (C)




         (A)                   (B)         LI-00246


       (A) Stop/tail light
       (B) Tail light
       (C) Stop light

2. WAGON
1) Remove the rear combination light assembly.

2) Turn the socket and remove the bulb.




                                           LI-00232

B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification.
3) If NG, replace the bulb with a new one.




                                                      LI-21
