Image preview - the first page of the document
>> Download 22. High-mounted Stop Light documenatation <<
Text preview - extract from the document
HIGH-MOUNTED STOP LIGHT
LIGHTING SYSTEM
22.High-mounted Stop Light 4) Remove screws (d), and then detach the high-
mounted stop light while disconnecting connector.
A: REMOVAL
1. SEDAN (STANDARD TYPE) (d)
1) Disconnect the ground cable from battery.
2) Disconnect the connector of high-mounted stop
light from body harness. (c)
3) Remove the bolts, then detach the high-mount-
ed stop light assembly.
(b)
(a)
LI-00036
B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
1) Visually check the bulb for blow out.
2) Check the bulb specification.
LI-00221
3) If NG, replace the bulb with a new one.
2. SEDAN (REAR SPOILER BUILT-IN
TYPE)
1) Disconnect the ground cable from battery.
2) Remove the bolts, then detach the high-mount-
ed stop light assembly.
3) Disconnect the connector of high-mounted stop
light from body harness.
LI-00222
3. WAGON
1) Disconnect the ground cable from battery.
2) Remove the cap (a) by prying on the edge with
screwdriver.
3) Remove the screws (b), and then the detach
cover (c).
LI-25
