                                      LUGGAGE ROOM LIGHT
LIGHTING SYSTEM

25.Luggage Room Light                                      2. LUGGAGE ROOM LIGHT SWITCH
A: REMOVAL                                                 Measure the luggage room light resistance.
1) Disconnect the ground cable from battery.
                                                                                  (3)            (1)
2) Remove the lens (A) and luggage room light
mounting screws (B).




                                                                                                (2)
                                                                                                          LI-00043


                                                               Switch position   Terminal No.            Standard
                                                                    OFF               --              More than 1 M
                                                                    ON             1 and 3              1.5
