Image preview - the first page of the document



>> Download 01. General Description documenatation <<

Text preview - extract from the document

                                       GENERAL DESCRIPTION
WIPER AND WASHER SYSTEMS

1. General Description
A: SPECIFICATIONS
Front wiper motor                      Input                                       12 V -- 72 W or less
Rear wiper motor                       Input                                       12 V -- 42 W or less
                                       Pump type                                       Centrifugal
Front washer motor
                                       Input                                       12 V -- 36 W or less
                                       Pump type                                       Centrifugal
Rear washer motor
                                       Input                                       12 V -- 36 W or less

B: COMPONENT
1. FRONT WIPER




                                                                    (4)
                                                               T1                                T1




                                                                                                  T1


                                                                                                            T2
                                                                                     (5)




                                                               T2



                                T1
                                                                                           (3)
                                                   (1)

       (1)



                                 (3)                     (2)




         (2)




                                                                                                          WW-00140


 (1)         Wiper rubber               (4)   Wiper link                  Tightening torque: N
