Image preview - the first page of the document



>> Download 04. Wiper Blade documenatation <<

Text preview - extract from the document

                                                WIPER BLADE
                                                                           WIPER AND WASHER SYSTEMS

4. Wiper Blade                                           D: ASSEMBLY
A: REMOVAL                                               1. METAL TYPE
While pushing the locking clip (A) up, pull out the      1) Insert the wiper rubber onto blade so that the
blade from arm to arrow direction.                       stopper is in the position shown.

            2                3

                                     (A)


                             2

                      3
                                 1


                                           WW-00064                                           WW-00049

B: INSTALLATION                                          2) Make sure the wiper rubber is securely fastened
1) Install in the reverse order of removal.              to the pull stopper (A).
2) Confirm that the clip is locked securely.
C: DISASSEMBLY
1. METAL TYPE
Pull on the side (A) of wiper rubber stopper, and
then remove the rubber from blade assembly.



                                                                                              WW-00037




                                           WW-00009

2. RESIN TYPE
Pull the wiper rubber top slightly from the stopper
(A) and pull it out fully.


                (A)




                                           WW-00143




                                                      WW-9
                                                 WIPER BLADE
WIPER AND WASHER SYSTEMS

2. RESIN TYPE




               A                                                                              D



                                             B                   C




                                                                                                     WW-00144



1) Insert the wiper rubber through the claw (B).        3) Insert the wiper rubber into the claw (A).



                                                                     A
           A
                                         B




                                         WW-00145                                                 WW-00147

2) Insert the wiper rubber top until it protrudes       E: INSPECTION
about 20 mm (0.79 in) from the stopper (D).             1) When the wiper does not perform well, inspect
                                                        the following:
