Image preview - the first page of the document
05. Washer Tank and Motor


>> Download 05. Washer Tank and Motor documenatation <<

Text preview - extract from the document
                                    WASHER TANK AND MOTOR
                                                                            WIPER AND WASHER SYSTEMS

5. Washer Tank and Motor                                  E: INSPECTION
                                                          Apply battery voltage to the connector terminal of
A: REMOVAL                                                the washer motor and make sure the motor oper-
1) Open the hood.                                         ates.
2) Disconnect the ground cable from battery.
3) Remove the two bolts, hose and connector, and
then remove the tank.




                                                                                               WW-00013



                                           WW-00011

B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
  6.0 N
