Image preview - the first page of the document
>> Download 06. Front Wiper Arm documenatation <<
Text preview - extract from the document
FRONT WIPER ARM
WIPER AND WASHER SYSTEMS
6. Front Wiper Arm C: ADJUSTMENT
Operate the wiper once. Align the wiper blade to
A: REMOVAL the ceramic print point mark (A) of front window
1) Open the hood. panel.
2) Remove the cap.
3) Loosen the nut to remove arm.
(A)
WW-00048
WW-00071
B: INSTALLATION
1) Install in the reverse order of removal.
2) Operate the wiper once.
3) Align the wiper blade to the ceramic print point
mark (A) of front window panel.
(A)
WW-00048
Tightening torque:
Refer to COMPONENT in General Descrip-
tion.
WW-12
