Image preview - the first page of the document
>> Download 07. Front Wiper Motor and Link documenatation <<
Text preview - extract from the document
FRONT WIPER MOTOR AND LINK
WIPER AND WASHER SYSTEMS
7. Front Wiper Motor and Link 5) Install in the reverse order of removal.
A: REMOVAL Tightening torque:
Refer to COMPONENT in General Descrip-
1) Disconnect the ground cable from battery.
tion.
2) Remove the cowl panel.
COMPONENT, General Description.>
3) Disconnect the connector of motor.
4) Loosen the bolts to remove wiper link. C: INSPECTION
1) When the battery is connected to the terminal of
connectors, confirm that the motor operates at low
speed.
3 2 1
5 4
WW-00150
5) Loosen the bolts and nuts to remove motor.
WW-00019
2) When the battery is connected to the terminal of
connectors, confirm that the motor operates at high
speed.
3 2 1
5 4
WW-00157
B: INSTALLATION
1) Connect the battery ground cable to battery.
2) To confirm that the motor is at auto stop position,
connect the harness to motor and turn the wiper WW-00020
switch ON/OFF once.
3) Disconnect the ground cable from battery. 3) Connect the battery to terminals of connector,
4) Tighten the nut where rod (A) and link plate (B) is and then remove the terminal connection with mo-
aligned in a straight line. tor rotated at low speed, and stop the wiper motor
through operation.
(A) (B)
3 2 1
5 4
WW-00153
WW-00021
WW-13
FRONT WIPER MOTOR AND LINK
WIPER AND WASHER SYSTEMS
4) Connect the battery and confirm that the motor
stops at automatic stop position after the motor op-
erates at low speed again.
3 2 1
5 4
WW-00022
WW-14
