09. Rear Wiper Arm


>> Download 09. Rear Wiper Arm documenatation <<

Text preview - extract from the document
                                          REAR WIPER ARM
WIPER AND WASHER SYSTEMS

9. Rear Wiper Arm
A: REMOVAL
1) Raise the wiper arm cover (A).
2) Loosen the nut to remove wiper arm.




                                       WW-00025

B: INSTALLATION
1) Install in the reverse order of removal.
2) Operate the rear wiper once.
3) Align the blade to rear defogger heat wire (A).


         (A)




                                       WW-00154

Tightening torque:
  Refer to COMPONENT in General Descrip-
  tion.

C: ADJUSTMENT
1) Operate the rear wiper once.
2) Align the blade to rear defogger heat wire (A).


         (A)




                                       WW-00154




                                                     WW-16
