Image preview - the first page of the document
10. Rear Wiper Motor


>> Download 10. Rear Wiper Motor documenatation <<

Text preview - extract from the document
                                       REAR WIPER MOTOR
                                                                         WIPER AND WASHER SYSTEMS

10.Rear Wiper Motor                                   C: INSPECTION
                                                      1) Connect the battery to wiper motor connector
A: REMOVAL                                            and confirm that the wiper motor operates.
1) Disconnect the ground cable from battery.
2) Remove the rear wiper arm.
3) Remove the cap (A), nut (B) and spacer (C) from                             2 1
rear wiper shaft.                                                              4 3




                                                                                             WW-00030

                                                      2) Connect the battery to terminal of connector,
                                                      and then remove the terminal connections with mo-
                                      WW-00027        tor rotated, and stop the wiper motor through oper-
                                                      ation.
4) Remove the rear gate lower trim.
5) Unclip the clip of harness, and then disconnect
the connector of wiper motor.
6) Loosen the bolts to remove the wiper motor as-                               2 1
sembly (A).                                                                     4 3

                           (A)



                                                                                             WW-00031

                                                      3) Connect the battery and confirm that the motor
                                                      stops at automatic stop position after the motor op-
                                                      erates at low speed again.

                                      WW-00155

B: INSTALLATION
1) Install in the reverse order of removal.                              2 1
                                                                         4 3
2) Install the rear wiper cushion with the arrow
mark facing up, as shown in the figure.



                                                                                             WW-00032




                                      WW-00029

Tightening torque:
  Refer to COMPONENT in General Descrip-
  tion.


                                                 WW-17
