WIPER CONTROL RELAY (WAGON MODEL)
WIPER AND WASHER SYSTEMS
12.Wiper Control Relay (Wagon 3) Measure the voltage when the wiper relay is op-
erated.
Model)
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the right quarter lower trim. 12 V
3) Loosen the nut to remove control unit. ON 0V
(3)
WW-00036
(1) Switch position
(2) Voltage
