                                                 RADIO BODY
                                                              ENTERTAINMENT

4. Radio Body
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the center panel while disconnecting
connector.




       : (A)                               ET-00076


       (A) Hook pawl

3) Remove the fitting screws, and slightly pull out
the radio from center console.




                                           ET-00077

4) Disconnect the harness connectors and antenna
feeder cord.
B: INSTALLATION
Install in the reverse order of removal.




                                                      ET-5
