Image preview - the first page of the document
>> Download 10. Noise Suppressor documenatation <<
Text preview - extract from the document
NOISE SUPPRESSOR
ENTERTAINMENT
10.Noise Suppressor B: INSTALLATION
Install in the reverse order of removal.
A: REMOVAL
1. SEDAN
1) Disconnect the ground cable from battery.
2) Remove the rear pillar upper trim.
3) Remove the rear shelf trim.
4) Disconnect the feeder cord connector from an-
tenna amplifier.
5) Disconnect the harness connector of noise sup-
pressor from terminal on glass antenna.
6) Remove the harness clip.
7) Remove the mounting nut and detach the noise
suppressor.
ET-00063
2. WAGON
1) Disconnect the ground cable from battery.
2) Remove the rear gate trim.
3) Disconnect the connector from noise suppres-
sor.
4) Remove the mounting nut and detach the noise
suppressor.
ET-00064
ET-11
