GENERAL DESCRIPTION
GLASS/WINDOWS/MIRRORS
1. General Description
A: COMPONENT
1. FIXED GLASS (SEDAN MODEL)
(8)
(2)
(4) (7)
(3)
(1) (5)
(8)
(3)
(6)
(5)
(2)
GW-00202
(1) Windshield glass (4) Rearview mirror mount (7) Spring
(2) Dam rubber (5) Locate pin (8) Fastener
(3) Molding (6) Rear window glass
GW-2
GENERAL DESCRIPTION
GLASS/WINDOWS/MIRRORS
2. FIXED GLASS (WAGON MODEL)
(6)
(2)
(4) (10)
(3)
(1) (5)
(6)
(9)
(8)
(8)
(6)
(7)
(2) (8)
(2)
GW-00203
(1) Windshield glass (5) Locate pin (9) Glass
(2) Dam rubber (6) Fastener (10) Spring
(3) Molding (7) Rear quarter glass
(4) Rearview mirror mount (8) Locate pin
GW-3
GENERAL DESCRIPTION
GLASS/WINDOWS/MIRRORS
3. FRONT DOOR GLASS
(9)
T1
(4)
T1
(1)
T1 (6)
T1
(5)
T1
(7)
(3)
T2
(2) T1
T2
(8)
T2
T2
GW-00248
