Image preview - the first page of the document
05. Front Regulator and Motor Assembly


>> Download 05. Front Regulator and Motor Assembly documenatation <<

Text preview - extract from the document
                     FRONT REGULATOR AND MOTOR ASSEMBLY
GLASS/WINDOWS/MIRRORS

5. Front Regulator and Motor                          B: INSTALLATION
   Assembly                                           1) Install in the reverse order of removal.
                                                      2) Adjust the front door glass.
1) Remove the door glass.                                Refer to COMPONENT in General Descrip-
2) Loosen the nuts to remove the rear sash.             tion.
                                                      C: INSPECTION
                                                      1) Make sure the power window motor rotates
                                                      properly when battery voltage is applied to the ter-
                                                      minals of motor connector.
                                                      2) Change polarity of battery connections to termi-
                                                      nals to ensure the motor rotates in reverse direc-
                                                      tion.

                                      GW-00221

3) Disconnect the motor connector.
4) Loosen the four bolts and two nuts to remove the
regulator assembly.




                                      GW-00222

5) Loosen the screw to remove motor assembly.




                                      GW-00223




                                                 GW-14
