Image preview - the first page of the document
>> Download 08. Outer Mirror Assembly documenatation <<
Text preview - extract from the document
OUTER MIRROR ASSEMBLY
GLASS/WINDOWS/MIRRORS
8. Outer Mirror Assembly 4) Disconnect the mirror connector.
5) Loosen the screws to remove the mirror assem-
A: REMOVAL bly.
1) Remove the scalp cap.
2) Remove the door trim.
3) Remove the mirror gusset cover.
: (1)
GW-00227
B: INSTALLATION
Install in the reverse order of removal.
GW-00061
(1) Hook
C: INSPECTION
Check to ensure that the rearview mirror moves properly when battery voltage is applied to terminals.
Mirror heater not-equipped model:
Switch position Terminal No.
OFF --
UP 4 (+) and 6 (-)
DOWN 6 (+) and 4 (-)
LEFT 5 (+) and 6 (-)
RIGHT 6 (+) and 5 (-)
If NG, replace the mirror.
Mirror heater equipped model:
Switch position Terminal No.
OFF --
UP 6 (+) and 8 (-)
DOWN 8 (+) and 6 (-)
LEFT 7 (+) and 8 (-)
RIGHT 8 (+) and 7 (-)
If NG, replace the mirror.
GW-17
