Image preview - the first page of the document
>> Download 10. Remote Control Mirror Switch documenatation <<
Text preview - extract from the document
REMOTE CONTROL MIRROR SWITCH
GLASS/WINDOWS/MIRRORS
10.Remote Control Mirror 3) Remove the remote control mirror switch from
console cover.
Switch
B: INSTALLATION
A: REMOVAL Install in the reverse order of removal.
1) Remove the console cover.
2) Disconnect the connector. C: INSPECTION
Move the rearview mirror switch to each position
and check continuity between terminals.
4 3 2 1
GW-00228 9 8 7 6
GW-00134
Change over switch right position:
Switch position Terminal No. Standard
OFF -- More than 1 M
UP 4 and 6, 2 and 1 Less than 1
DOWN 6 and 2, 4 and 1 Less than 1
LEFT 4 and 8, 2 and 1 Less than 1
RIGHT 8 and 2, 4 and 1 Less than 1
Change over switch left position:
Switch position Terminal No. Standard
OFF -- More than 1 M
UP 4 and 7, 2 and 1 Less than 1
DOWN 7 and 2, 4 and 1 Less than 1
LEFT 4 and 9, 2 and 1 Less than 1
RIGHT 9 and 2, 4 and 1 Less than 1
If NG, replace the switch.
GW-19
