                                                         GENERAL DESCRIPTION
SEATS

1. General Description
A: COMPONENT
1. FRONT SEAT



                                                          (1)

                                                                                   (3)
                                                                                                                    (4)


                                                   (2)                                                                           (6)
                                                                                                                                             T1

                                                                                                                                                    (7)
                             (9)                                                                              (5)
                                                 (10)




                     (11)
               T5
                        (12)                                                             T6
                                                                                                                                       (8)

                            (13)
                                                                                (19)

                     (14)

              (23)                                                                                   (17)


       T2


                                                                                              (16)
              T2

                                   (21)
                                                                                                             (15)         (18)
                                          (22)

               T7                                                                                             T7                 T3
                                                                          T4
                                                 T3
                                                           (20)



                                                                                                                                                  SE-00280


 (1)        Backrest cover                               (12)     Seat cushion cover                        (23)     Inner belt
 (2)        Backrest pad                                 (13)     Seat cushion pad
 (3)        Backrest frame ASSY                          (14)     Seat cushion frame ASSY                   Tightening torque: N
