Image preview - the first page of the document
>> Download 19. Remote Openers documenatation <<
Text preview - extract from the document
REMOTE OPENERS
SECURITY AND LOCKS
19.Remote Openers 6) Remove the cable from striker.
A: REMOVAL
1. HOOD OPENER
1) Remove the release cable from hood lock. (1)
2) Remove the bolt. Remove the opener lever. (2)
SL-00120
(1) Striker
(2) Cable
3. FUEL FLAP OPENER
SL-00089
1) Remove the rear seat.
2) Remove the center pillar lower trim, and remove
1) Remove the rear seat. rear pillar lower trim. Pull back the floor mat. Re-
2) Remove the center pillar lower trim, and remove move the clip holding the cable.
the side sill cover on passenger side. Remove the 3) Remove the bolt. Remove the opener pull han-
rear pillar lower trim. Pull back the floor mat. Re- dle.
move the clip holding the cable.
3) Remove the bolt. Remove the opener pull han- (2)
dle. (3)
(1)
(2)
(3)
(1) (4)
(5)
(4)
(5) SL-00119
(1) Sedan
SL-00119
(2) Wagon
(3) Cover
(1) Sedan
(4) Pull handle ASSY
(2) Wagon
(5) Cable
(3) Cover
(4) Pull handle ASSY 4) Remove the cable from opener pull handle.
(5) Cable 5) Remove the right rear quarter trim.
4) Remove the cable from opener pull handle.
5) Remove the striker from trunk lid.
SL-42
REMOTE OPENERS
SECURITY AND LOCKS
6) Rotate the fuel lock inside the quarter panel to
left and remove.
SL-00023
B: INSTALLATION
1. HOOD OPENER
Install in the reverse order of removal.
2. TRUNK LID OPENER
Install in the reverse order of removal.
3. FUEL FLAP OPENER
Install in the reverse order of removal.
C: INSPECTION
Make sure the fuel flap opens and closes smoothly.
SL-43
