Image preview - the first page of the document



>> Download 01. General Description documenatation <<

Text preview - extract from the document

                               GENERAL DESCRIPTION
EXTERIOR/INTERIOR TRIM

1. General Description
A: COMPONENT
1. FRONT GRILLE


                                                          (3)




                                                                            (1)


                         (2)


                                                                                                      EI-00413


 (1)   Front grille            (2)   Front grille emblem                (3)       Clip

2. UNDER COVER



                                                                (1)




                                                    T



                                                                      (2)
                                                                                                      EI-00414


 (1)   Under cover             (2)   Clip (side)                      Tightening torque: N
