Image preview - the first page of the document
>> Download 03. Hood Grille documenatation <<
Text preview - extract from the document
HOOD GRILLE
EXTERIOR/INTERIOR TRIM
3. Hood Grille 2) Engage the four clips of hood grille to front hood
panel.
A: REMOVAL CAUTION:
1) Remove the hood insulator. Make sure that the anchor portion of each clip
2) Remove the seven bolts and clip (A) to remove is firmly engaged.
the hood duct.
(A)
EI-00447
EI-00444
3) Install the five nuts.
3) Loosen the six nuts (B), remove the four clips
(A), and then remove the hood grille. Tightening torque:
4.5 N◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
