Image preview - the first page of the document



>> Download 05. Front Bumper documenatation <<

Text preview - extract from the document

                                          FRONT BUMPER
                                                                             EXTERIOR/INTERIOR TRIM

5. Front Bumper                                       5) Remove the two clips (A), turn over the mud
                                                      guard, and then remove the clip (B). (Conduct the
A: REMOVAL                                            same procedure on the right side.)
1) Disconnect the ground cable from battery.
2) Remove the front grille.
3) Remove the nine clips on the upper part of                (A)
bumper.




                                                                   (B)
                                       EI-00548

4) Turn over the mud guard, and then remove the
clips (A) and (B), which secure the front bumper to
fender.


                                                                                            EI-00435

                                                      6) Remove the four clips in the center part of
                                                      bumper.




                                                                                            EI-00436

                                                      7) Remove the fog light.
                                                      8) Remove the bumper from body.
                                                      9) Remove the energy absorber foam.
                                       EI-00522




                                                                                            EI-00437




                                                  EI-23
                                                 FRONT BUMPER
EXTERIOR/INTERIOR TRIM

10) Loosen the bolt and nut, and then remove the                    B: INSTALLATION
bumper beam from body.                                              1) Install in the reverse order of removal.
                                                                    2) Secure the slider (A) to guide plate (B).


                                                                                                   (B)




                                                                                          (A)


                                              EI-00439

                                                                                                                        EI-00521

                                                                    Tightening torque:
                                                                      Refer to COMPONENT in General Descrip-
                                                                      tion.

C: REPAIR
1. COATING METHOD FOR PP BUMPER
  Pro-
  cess     Process name                                                    Job contents
  No.


                                                                                       (1)


                              Set the bumper on paint worktable if required.
   1     Bumper mounting      Use paint worktable conforming to inner shape
                              of bumper when possible.

                                                                                                         (2)
                                                                                                                            EI-00234
                                                                               (1) Bumper
                                                                               (2) Set bumper section
                              Mask specified part (black base) with masking tape. Use masking tape for PP (example, Nichiban
   2     Masking
                              No. 533, etc.).
         Degreasing, clean-
   3                          Clean all parts to be painted with white gasoline, normal alcohol, etc. to remove dirt, oil, fat, etc.
         ing
   4     Primer paint         Apply primer one to all parts to be painted, using air gun. Use primer (clear).
                              Dry at normal temperature [10 to 15 min. at 20
